compressor Oil-injected
screw compressors

Oil-injected screw compressors with a delivery track record of over 1,000 units for users all over the world

KOBELCO started to manufacture and provide oil-injected screw compressors in 1974. Since then, we have delivered over 1,000 units to users inside and outside of Japan for use in a large number of applications. Examples include hydrogen gas, helium gas, coke oven gas, and gas turbine fuel gas. A recent example is low-pressure engine fuel gas for LNG carriers.

Overview

Oil-cooled (wet) screw compressors inject oil into the compressor chamber. The applied oil creates a seal between the rotors that improves volumetric efficiency, making these compressors suited to applications involving high pressures and compression ratios. The compressor capacity can be adjusted by a slide valve mechanism, reducing energy losses from load fluctuation.

油冷式(WET)スクリュ圧縮機

Product Description

Single-stage models (one-stage compression) and tandem models (two-stage compression) are available.
Models with maximum airflow of 34,000 m3/h (for suction) and maximum discharge pressure of 100 bar(g) are available.
The capacity can be adjusted with a slide valve (from 15 to 100%), enabling energy-saving operation.
KOBELCO's proprietary oil-separation system design minimizes the amount of oil contamination in the process gas.
The optimum lubricant oil type can be selected to match the process gas and application. Kobelco-branded oils can be supplied.
The lineup includes an advanced wet screw compressor that inhibits the effects that the process gas dissolved in the lubricant oil has on the bearings.
